Digital Yacht GPS160F GNSS Sensor ZDIGGPS160F w/Furuno Format Data Output
$297.99
Only 7 left - ships same or next business dayEstimated delivery: Thu, Oct 29 – Tue, Nov 3From the entry
Brand new in original packaging.
- Digital Yacht GPS160F is a QuadNav GNSS sensor (GPS, GLONASS, Galileo, BeiDou) designed as a drop-in replacement for legacy Furuno positioning sensors.
- Outputs legacy NMEA 0183 sentences and data formats compatible with older Furuno plotters, radars and sounders (e.g. GP310, GP320, NavNet, VX2, M1735, GP7000, FCV series).
- Ultra-low power draw of under 20mA at 12V DC, simple 4-wire installation, and works straight out of the box.
- Supplied with a 10-metre cable and a dedicated user manual covering Furuno interfacing.
- Configurable via internal DIP switches for multiple NMEA output formats, datum information, and baud rates (4800/38400/115200).
- Refined anti-spoofing algorithm improves position reliability and interference rejection.
- Typical position accuracy better than 1 metre with update rates up to 18Hz for smoother plotter tracking.
- Solves GPS week-rollover failures common in older Furuno sensors, offering an economical, reliable fix.
Specifications
| Brand | Digital Yacht |
| MPN | ZDIGGPS160F |
| UPC | 703791696390 |
| Product Type | Marine GNSS positioning sensor with Furuno-format NMEA 0183 output |
| Output Format | NMEA 0183 (Furuno legacy compatible) |
| Power Consumption | <20mA at 12V DC |
| Cable Length | 10 m supplied cable |
| GNSS Constellations | GPS, GLONASS, Galileo, BeiDou (72-channel QuadNav engine) |
| Position Accuracy | Better than 1 m typical |
| Update Rate | Up to 18 Hz |
| Baud Rate Options | 4800 / 38400 / 115200 via DIP switches |
| Net Weight | 514 g (approx. 1.13 lb) |
| In the Box | GPS160F sensor, 10 m cable, user manual |
What's Included
- Digital Yacht GPS160F GNSS sensor
- 10 m cable
- User manual with Furuno interfacing information
Shipping & Returns
Fast, free shipping from our US warehouse.
Returns accepted per our store return policy.
Specifications
| MPN | ZDIGGPS160F |
|---|---|
| Type | Marine |
| Brand | Digital Yacht |
| Model | GPS160F |
